Overnight, those of you in the Americas and well out into the Pacific Ocean, if graced with clear skies, will be able to observe what is known as “a total eclipse of the Moon” or a “lunar eclipse”. The Moon’s color will turn orange for about 80 minutes, with mid-eclipse occurring simultaneously in all the areas in which the eclipse is visible: 3:00-4:30 am for observers in New York, 12:00- 1:30 am for observers in Los Angeles, and so forth. [As a bonus, Mars will be quite near the Moon, and about as bright as it gets; you can’t miss it, since it is red and much brighter than anything else near the Moon.]
Since the Moon is so bright, you will be able to see this eclipse from even the most light-polluted cities. You can read more details of what to look for, and when to look for it in your time zone, at many websites, such as http://www.space.com/25479-total-lunar-eclipse-2014-skywatching-guide.html However, many of them don’t really explain what’s going on.
One striking thing that’s truly very strange about the term “eclipse of the Moon” is that the Moon is not eclipsed at all. The Moon isn’t blocked by anything; it just becomes less bright than usual. It’s the Sun that is eclipsed, from the Moon’s point of view. See Figure 1. To say this another way, the terms “eclipse of the Sun” and “eclipse of the Moon”, while natural from the human-centric perspective, hide the fact that they really are not analogous. That is, the role of the Sun in a “solar eclipse” is completely different from the role of the Moon in a “lunar eclipse”, and the experience on Earth is completely different. What’s happening is this:
- a “total eclipse of the Sun” is an “eclipse of the Sun by the Moon that leaves a shadow on the Earth.”
- a “total eclipse of the Moon” is an “eclipse of the Sun by the Earth that leaves a shadow on the Moon.”
In a total solar eclipse, lucky humans in the right place at the right time are themselves, in the midst of broad daylight, cast into shadow by the Moon blocking the Sun. In a total lunar eclipse, however, it is the entire Moon that is cast into shadow; we, rather than being participants, are simply observers at a distance, watching in our nighttime as the Moon experiences this shadow. For us, nothing is eclipsed, or blocked; we are simply watching the effect of our own home, the Earth, eclipsing the Sun for Moon-people.
Simple geometry, shown in Figure 1, assures that the first type of eclipse always happens at “new Moon”, i.e., when the Moon would not be visible in the Earth’s sky at night. Meanwhile the second type of eclipse, also because of geometry, only occurs on the night of the “full Moon”, when the entire visible side of the Moon is (except during an eclipse) in sunlight. Only then can the Earth block the Sun, from the Moon’s point of view.
An total solar eclipse — an eclipse of the Sun by the Moon, as seen from the Earth — is one of the nature’s most spectacular phenomena. [I am fortunate to speak from experience; put this on your bucket list.] That is both because we ourselves pass into darkness during broad daylight, creating an amazing light show, and even more so because, due to an accident of geometry, the Moon and Sun appear to be almost the same size in the sky: the Moon, though 400 times closer to the Earth than the Sun, happens to be just about 400 times smaller in radius than the Sun. What this means is that the Sun’s opaque bright disk, which is all we normally see, is almost exactly blocked by the Moon; but this allows the dimmer (but still bright!) silvery corona of the Sun, and the pink prominences that erupt off the Sun’s apparent “surface”, to become visible, in spectacular fashion, against a twilight sky. (See Figure 2.) This geometry also implies, however, that the length of time during which any part of the Earth sees the Sun as completely blocked is very short — not more than a few minutes — and that very little of the Earth’s surface actually goes into the Moon’s shadow (see Figure 1).
No such accident of geometry affects an “eclipse of the Moon”. If you were on the Moon, you would see the Earth in the sky as several times larger than the Sun, because the Earth, though about 400 times closer to the Moon than is the Sun, is only about 100 times smaller in radius than the Sun. Thus, the Earth in the Moon’s sky looks nearly four times as large, from side to side (and 16 times as large in apparent area) as does the Moon in the Earth’s sky. (In short: Huge!) So when the Earth eclipses the Sun, from the Moon’s point of view, the Sun is thoroughly blocked, and remains so for as much as a couple of hours.
But that’s not to say there’s no light show; it’s just a very different one. The Sun’s light refracts through the Earth’s atmosphere, bending around the earth, such that the Earth’s edge appears to glow bright orange or red (depending on the amount of dust and cloud above the Earth.) This ring of orange light amid the darkness of outer space must be quite something to behold! Thus the Moon, instead of being lit white by direct sunlight, is lit by the unmoonly orange glow of this refracted light. The orange light then reflects off the Moon’s surface, and some travels back to Earth — allowing us to see an orange Moon. And we can see this from any point on the Earth for which the Moon is in the sky — which, during a full Moon, is (essentially) anyplace where the Sun is down. That’s why anyone in the Americas and eastern Pacific Ocean can see this eclipse, and why we all see it simultaneously [though, since we’re in different time zones, our clocks don’t show the same hour.]
Since lunar eclipses (i.e. watching the Moon move into the Earth’s shadow) can be seen simultaneously across any part of the Earth where it is dark during the eclipse, they are common. I have seen two lunar eclipses at dawn, one at sunset, and several in the dark of night; I’ve seen the moon orange, copper-colored, and, once, blood red. If you miss one total lunar eclipse due to clouds, don’t worry; there will be more. But a total solar eclipse (i.e. standing in the shadow of the Moon) can only be seen and appreciated if you’re actually in the Moon’s shadow, which affects, in each eclipse, only a tiny fraction of the Earth — and often a rather inaccessible fraction. If you want to see one, you’ll almost certainly have to plan, and travel. My advice: do it. Meanwhile, good luck with the weather tonight!
